A new type of power system equipment that integrates energy storage technology, power electronics technology, and mobile carrier technology can provide stable and reliable power support in various environments. It typically utilizes renewable energy and is connected to the grid or used independently to meet the electricity demand in different scenarios.
| Parameter | numerical value | |
| Communication side parameters | Communication access method | 3P+N+PE |
| Voltage range of power grid | 400V±15% | |
| Grid frequency range | 50Hz±2.5Hz | |
| Charging power of energy storage battery | 125kW | |
| Discharge power of energy storage battery | 125kW | |
| Number of photovoltaic access channels | 1 Road | |
| Photovoltaic access power | 100kW | |
| Photovoltaic access power | 200V~1000V | |
| Output constant power range | 300V~1000V | |
| Electric vehicle charging power | 120kw | |
| Current range | 0~200A | |
| Battery side parameters | Type | LiFePO₄ |
| Single cell battery | 3.2V/314Ah | |
| rated energy | 418kWh | |
| nominal voltage | 665.6V | |
| Operating voltage range | 561.6V~748.8V | |
| composition | 1P208S*2 | |
| Magnification | ≤0.5C | |
| COOLING SYSTEM | Liquid cooling | |
| Fire Protection System | Perfluorohexane gas fire protection | |
| Charging port parameters | Number of charging guns | akimbo（5m） |
| output current | Max:100A Single-gun | |
| Auxiliary power supply | 12V | |
| Environmental parameters | temperature range | -15℃~50℃ |
| relative humidity | 5%~95% | |
| Working altitude | ≤2000m | |
| protection grade | IP54 | |
| External dimensions | 1600mm*2300mm*1860mm（Width * Depth * Height） | |
| weight | ≤3800kg | |
